DB-162P
Bycon
The BYCON DB-162P is a compact yet powerful micro percussion core drill motor, purpose-built for precision drilling in reinforced concrete, brick, and other abrasive materials. Its 2200W motor, combined with a switchable micro percussion mode and two-speed gearbox, delivers smooth and efficient dry drilling performance. Weighing just 6.5 kg, this lightweight motor is ideal for both handheld and rig-mounted use. A mechanical slipping clutch, ergonomic handle, and soft start feature ensure maximum control and safety. Compatible with standard European 1¼″ UNC and ½″ BSP core bits, it’s the perfect solution for contractors seeking control, portability, and professional-grade results.
Key Features
2-Speed Gear Regulation: Adaptable to material type and desired diameter
Micro Percussion Mode: Improves efficiency in dry drilling through hard concrete
Soft Start Function: Gradual acceleration protects the motor and operator
Adjustable Front Handle: Ergonomically designed for comfort and stability
Dual Use Design: Suitable for handheld or rig-mounted drilling (60 mm clamp bracket)
Mechanical Slip Clutch: Prevents overload and enhances safety
Thread Compatibility: Fits standard 1¼″ UNC and ½″ BSP core bits
Technical Specifications
Power Output: 2200 W
Voltage: 220 V / 120 V
Current: 10 A / 15 A
Frequency: 50 / 60 Hz
Max Drilling Diameter (Handheld): Ø162 mm
Max Drilling Diameter (With Stand): Ø202 mm
Drilling Diameter (Gear 1 & 2): Ø162 mm / Ø82 mm (handheld), Ø202 mm / Ø102 mm (with stand)
No-Load Impact Speed: 16,000 / 38,000 rpm
Speed Settings: 700 / 1,550 rpm
Spindle Thread: 1¼″ UNC & ½″ G
Net Weight: 6.5 kg
Compatible Drill Stand: DSP-162 / DSP-252
Packing Size: 635 × 460 × 215 mm
What’s Included
BYCON DB-162P Drill Motor (2200 W)
Adjustable Side Handle
Water Connection Adapter
Instruction Manual
